Big bag inlet and outlet spout sewing machine

Big bag inlet and outlet spout sewing machine

Big bag inlet and outlet spout sewing machine GK80900-CD5 is the high speed, two needle, four thread, cylinder-bed, heavy duty chainstitch industrial sewing machine. It is onespecial designed machine with the round cylinder to sew the jumbo bag filling and discharging spout with/without filler cord from the top and bottom, very suitable for the skirt bags. Its 360 degree round cylinder bed can help insert into the inlet and outlet spout tube, which help the 360 degree circle stitch to attach the big bag.

With the bottom and top alternative feeding structure, this big bag inlet and out spout sewing machine has two independent rows of chain stitches(401+401 type), the standard set up of this machine comes with pneumatic foot lift device, automatic thread chain cutter(hot knife), top and bottom filler cord guides, top oil bath with auto lubrication,750W powerful needle position servo motor with the external synchronizer and special designed table and stand with the heavy thread stand for the big bag thread.

In addition, the machine can be customized to the single needle two thread version, as well as without air foot lift and manual thread cutting depends on the actual requests.

● Cylinder-bed heavy duty chainstitch big bag sewing machine.

● Powerful upper and lower feed mechanism

● Max.sewing speed can up to 1600SPM.

● Pneumatic foot lift and hot thread chain cutter(burner).

● Filler cord guide from top and/or bottom
