Compared with the automatic vertical bag label attaching machine with DS-9C, the horizontal bag label attaching machine has updated these days, we will share some information for the machine, and hope it will help you.
1. How does it work?
Core working principle: When the bag passes by the sensor, it sends a signal back to the label delivery control system. At the appropriate position, the conveyor belt transports the label to the bottom front of the sewing machine press foot. The label is then introduced into the sewing machine and sewn onto the surface of the bag opening. Meanwhile, the next label reaches the waiting position and waits. This action is completed.
2.What are the relevant technical parameters?
(The following are the technical parameters of the standard model. Other special requirements and functions can be customized)
(1) Applicable label length: 120 - 170mm
(2) Applicable label width: 70 - 100mm
(3) The speed of label delivery can be adjusted according to the speed of the bag delivery
(4) Applicable label materials: 80 - 128 grams of kraft paper, offset paper, and board paper
3.What are the characteristics of the machine?
①Synchronous Tag & Bag Processing:
Tags are automatically fed and positioned together with bags, secured during closing, no separate labeling workstation required.
②Flexible Tag Compatibility:
Accommodates multiple standard tag sizes; tag position, feed timing and spacing are adjustable via PLC controller for fast recipe switching.
③Reliable Bag Closing Performance:
Works with multi-wall paper sacks, woven polypropylene bags and PE liner bags. Stitch closure delivers strong, consistent seam strength for heavy-duty bulk packaging.
④Sensor-Guided Automation:
Photoelectric sensors detect bag presence to trigger tag feeding, preventing mis-feeds, missing tags or double-tag faults, with alarm prompts for jams or tag depletion.
⑤High Throughput:
Boosts packaging line efficiency and uniformity. Reduces repetitive manual work, lowers operating cost and improves traceability of packed goods.
4.In which fields is this machine applied?
Ideal for bulk packaged products including grains, rice, flour, animal feed, seeds, fertilizers, plastic resins, mineral powders and food additives. Perfect for factories requiring permanent sewn-on tags for quality traceability and regulatory identification.
If you are intereted in the machine, please kindly contact us ,
